DTF-6002 STAR IV Industrial 2-Head DTF Printer with Automatic Powder Shaker & Dryer
The SUBLISTAR DTF-6002 STAR IV is a complete industrial DTF printing system combining a high-performance 2-head DTF printer with a perfectly matched automatic powder shaker and dryer. Designed for stable production, vivid color output, and efficient post-printing processing, it provides an ideal solution for custom apparel manufacturers, print shops, and growing Print-on-Demand (POD) businesses seeking reliable productivity and consistent transfer quality.
Technical Highlights:
- Print Head: 2*Epson I3200 Heads
- Print Size: 24″(600mm)
- Print Speed: 102/h
- Ink Type: C,M,Y,K+W
Top Features:
- White Ink Filtration & Circulation System: prevents ink deposits from clogging the printhead, and extends the life of the printhead.
- Nozzle Recovery System: effectively solves the problem of partial clogging of the printhead holes, and allows the machine to continue to run until a repairman comes to the house.
- Intelligent Platform Heaters: provide front, center, and rear heating to keep media warm and ink dry for high-quality output.
- Simultaneous White & Full Color Printouts, accurate white and color ink coverage with no white space. Features a wide color gamut and gradient colors.
Warranty: 24 months (Ink system, printheads and ink capping are not covered)
International Shipping: DHL, FedEx, By Air, By Sea
Scalable Design, Super Stability
The DTF-6002 STAR IV is engineered as a complete Direct-to-Film (DTF) printing solution, integrating high-speed printing with automated powder application and curing in one coordinated workflow.
Powered by two Epson printheads and paired with SUBLISTAR’s automatic powder shaker & dryer, the system delivers outstanding print quality, stable white ink performance, and reliable continuous production. It is suitable for cotton, polyester, blends, nylon, canvas, and many other textile materials.
Complete DTF Printing Solution
Includes a 2-head DTF printer and a matched automatic powder shaker & dryer, providing a fully integrated workflow from printing to transfer-ready film.
Consistent Colour Performance
Deliver vibrant colours, balanced white ink, and excellent repeatability, ensuring consistent transfer quality across every production batch.
Stable Commercial Output
Designed for continuous operation with intelligent white ink circulation and a matched powder shaker & dryer, ensuring reliable production and fewer interruptions.
Vibrant Color & Excellent Wash Durability
Produces vivid colors, high opacity white ink, and durable transfers with excellent stretchability and wash resistance.
Meet Sublistar 6002 Star IV DTF Printing Machine
Professional Features - Sublistar DTF Printer
Print Head Heating Available
Ink damper with external heating and carriage plate that releases heat. The printer can operate correctly in an environment with significant temperature fluctuation thanks to this technology. The heating feature can guarantee the ink’s good fluidity during the printing process.
Advanced Paper Pass system
Motor-controlled paper travel and industrial-grade platen rollers increase the stability and reliability of the printing process and prevent creasing and other printing-related problems. In the printing and output process, good printing accuracy is guaranteed.
Mute Linear Guide
Quiet operation and stability. Low noise, high speed, extended service life, and long-term operation without maintenance are all achieved by significantly reducing friction between the silent guide rail’s sliders and improving the retention of lubricating grease.
Japan 3M Filter
Large particles, gels, and other contaminants are efficiently caught by our imported filter, which also permits the necessary color dyes to pass through and stay in the ink. The imported filter offers a superior capacity for impurity filtration and a longer lifespan.
One-click automatic lifting
The DSP-S10 I series enables fully automatic lifting and retracting, eliminating the need for the operator to laboriously lift the oven. Save time, save labor, and save your mind.
Friendly Anti-suction Cooling Fan
User-friendly to prevent hair, clothing, etc. from being sucked in, especially for female workers to protect personnel safety when collecting printed film. Also cools and handles high-temperature curing film for better pattern color rendering.
Epson I3200-A1 Print Head
Epson I3200-A1 print heads are used in the DTF-600 Series STAR IV DTF Fluorescent printer. The Epson I3200 head boasts 3200 nozzles, a 600 dpi resolution, higher jetting frequency than DX5 and XP600, better color saturation, faster printing, and more accurate printing, all for a low price. Very economical.
| Model | I3200-A1 |
| Ink Types | Water based ink |
| Size(width x depth x height)(mm) | 69.1×59.4×35.6 |
| Weight(g) | 82 |
| Nozzle Numbers | 3200 |
| Length Between Nozzles(inch) | 1/300(in one row) |
| Nozzle Row | 8 row |
| Max color/head | 4 colors |
| Resolution | 300 npi/1 row 600 npi/2 rows |
| Effective Printing Width(mm) | 33.8 |
| Jet Freqency(kHz) | 43.2 (single dot), 21.6 (multi dot) |
| Ink Drops(pl) | 3.8-6-12(9.4) |
| Ink Viscosity(mPa.s) | 3~4 |
Product Specifications - DTF-6002 STAR IV DTF Printer
| DTF-6002 Star IV Inkjet Printer | |
| Model | DTF-6002 Star IV |
| Brand | Sublistar |
| Print Head Type | PrecisionCore Epson I3200*2 |
| Print Resolution/Speed | 4pass: 12m² /hour |
| 6pass: 8m²/hour | |
| 8pass: 6m²/hour | |
| Maximum Printing Width | 620mm |
| Color Mode | C,M,Y,K+W |
| RIP Software | FlexiPRINT, CADlink, NeoStampa, PrintFactory |
| Interface | Network Port |
| Dimensions | 1766*750*1513mm (L*W*H) |
| Package Size | 1880*1060*740mm (L*W*H) |
| Package Weight | 210KG |
| Powder Shaker & Dryer | |
| Model | DSP-600(S10i) |
| Brand | Sublistar |
| Operation Mode | SCM Touch Screen |
| Max Working Width | 600mm |
| Oven Length | 1080mm |
| Oven Temp. | Adjustable |
| Voltage | 110v/220v, 3phase, 60Hz |
| Power | 3.5-4KW |
| Package Size | 1900mm L x 980mm W (with Air Filter) x 900mm H |
| Package Weight | 285KG |
T Shirt (DTF) Printing Process
Design Pattern
Create your pattern using software like Illustrator, Photoshop, or another program.
Publish Your Creation
Utilize our printer and ink to print your pattern after modifying the printer settings in the RIP software.
Powdering
When the powder shaking machine's switch is turned on, the machine will automatically powder, dry, and set the color.
Heat Press
Utilize a heat press, set the temperature to 180 degrees, and provide the transfer 15 seconds.
DTF Applications
Ideal for: Custom T-shirt Printing, Print-on-Demand (POD), Promotional Products, Sportswear, Workwear, Small-to-Medium Garment Factories.
Exclusive Offer: BUY 1 GET More !
Buy SUBLISTAR DTF printer online, get premium quality DTF printing starter kit supplies for free.
DTF Starter Kit Includes:
- Film: 0.6m*100m/0.3m*100m roll size
- DTF Powder: 5 kg (11 lbs)
- DTF Ink: 1000ml*6 (c,m,y,k+ww)
- Rip software: Flexi Print/Maintop
- Sublistar DTF environment settings
- Sublistar DTF instructional video
FAQ
What is dtf printing?
DTF standard (direct to film) is a new technology with the advantage of printing crisp and clean transfers on light or dark shirts. This printing method can print on 100% cotton, polyester, 50/50 blends, leather, nylon and more.
What is the quality of DTF Printing?
Unlike other laser and ink transfers, the printer leaves a lower quality product after the first two washes. The DTF printing method held up really well and left no cracks on the imprint.
What is the difference between DTF and DTG?
Please send a detailed description, photos, or videos to our technicians, who will analyze the problem and give the appropriate solution within the first time receiving the information.
What is the cost for DTF?
The cost for DTF is much less than DTG by about 10-15%. If your needing a quick shirt and don’t want to pay much then the best print solution is DTF.
How is your quality control?
We have a professional quality control team that performs 100% testing before delivery.
How do I order a machine from you?
After you confirm the order details, we will send you a pro-forma invoice for confirmation. After payment is received, we will arrange production.
The shipping method is communicated to you and the final shipping product will be sent out within the agreed time.
